NaClO Solution Sodium Hypochlorite Generator Advantage Analysis 3 kg / h

NaClO Solution Sodium Hypochlorite Generator Advantage Analysis 3 kg / h

    • NaClO Solution Sodium Hypochlorite Generator Advantage Analysis 3 kg / h
    • NaClO Solution Sodium Hypochlorite Generator Advantage Analysis 3 kg / h
    • NaClO Solution Sodium Hypochlorite Generator Advantage Analysis 3 kg / h
  • NaClO Solution Sodium Hypochlorite Generator Advantage Analysis 3 kg / h

    Product Details:

    Place of Origin: CHINA
    Brand Name: CNJS
    Certification: ISO9001
    Model Number: CNJS-N-3000

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: NEGOTIATION
    Packaging Details: wooden case
    Delivery Time: 20-45 work days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 20 SETS PER MONTH
    Contact Now
    Detailed Product Description
    Available Chlorine: 0.8 % Inlet Water Temperature: 5-27℃
    Inlet Water Pressure: 0.2-0.4Mpa Salt Consumption: 3.5kg/kg Cl2
    Water Consumption: 125L/kg Cl2
    High Light:

    Onsite Sodium Hypochlorite Generation

    ,

    Sodium Hypochlorite Solution For Disinfection


    NaClO Solution Sodium Hypochlorite Generator Advantage Analysis 3 kg / h



    Product introduction:

    Generation principle :CNJS - M series NaClO generator is a new type of NaClO solution for field production equipment , suitable for all kinds of needs NaClO disinfected venues . Its working principle is: the sodium chloride solution under the certain cell voltage function, in a series of electrochemical reaction occurs in the cell , the resulting NaClO solution , including the generation of NaClO through chemical equation can be expressed as follows :



                                                            NaCl+H2O+DC→NaClO+H2



    The electrode reaction:

    anode:2Cl--2e→Cl2

    cathode:2H++2e→H2

    solution:2NaOH+Cl2→NaCl+NaClO+H2O


    Technical parameters:


    Type

    Power(V/Hz)

    concentration of liquid(mg/l)

    available chlorine (Kg/h)

    Flow (m3/h)

    Salt consumption (kg/d)

    Water consumption (m3/d)

    Power consumption   (kw)

    Size(m)      (l×w×h)

    CNJS-N3000

    380V/50Hz

    7-9

    3

    0.375

    252

    9

    17.5

    900*700*1780



    Compared with commercial sodium hypochlorite disinfection methods

    Disinfection method

    On-site
    Sodium hypochlorite

    Commercial
    Sodium hypochlorite




    Making process

    It produce a solution of

    strengths 0.8% and the only
    raw materials required are
    salt and water and electricity, so it has a

    PH of 9 and making it less likely to cause scaling

    By-product of the chlor-alkali industry, the concentration of 10%, containing excess alkali and harmful impurities



    Attenuation

    Without attenuation

    Attenuation of 5% per day, and also cause excessive Chlorate in dinking water



    Safety

    Safety disinfection method, environmental non-toxic, liquid dosage

    Dangerous articles. Risk during transport and storage and easily caused degradable when storage. Short time storage and high transport costs. Liquid dosing



    Disinfection by-products

    Due to weak in chlorine oxidation ability, three material are less, and combined additive, ammonia, potassium permanganate, less by-products

    The raw material is

    Industrial salt, which contain harmful impurities in drinking water and it is bad for health.



    Economic analysis

    The investment is a little higher in the early time, but the operation cost is low, and after three or four years it can pay your investment money back

    Equipment cost is low, but the high cost of running, and the running costs can not be controlled



    Dosing Accuracy

    Dosing liquid low concentration, can accurately control the amount of chlorine

    High concentration, difficult to precisely control the amount of chlorine, dosing hole easily plug fouling




    ECONOMIC ANALYSIS:

    If Water sewage treatment plant 20000 T/D, need 3kg per hour

    On-site Sodium Hypochlorite

    Unit raw material consumption:

    DC Power consumption : 4.5kW·h/Kg Cl2
    Salt consumption : 3.5Kg/Kg Cl2

    Daily energy consumption:

    •  Daily power consumption::72 x 4 =288 kW·h
    •  Daily salt consumption 72 x 3.5 =252Kg
    •  Daily water consumption:72 x 0.125 =9m3



    •  The raw material price:
    • The average power price : 0.11usd/ kW·h
    • salt price : 0.13usd/Kg
    • water fee : 0.33usd/m3

    Daily operation cost  :

    Power charge  :288× 0.11=31.68usd
    Salt fee : 252 × 0.14 =32.76usd
    Water fee : 9 × 0.33 =2.97usd
    Total fee : 31.68+32.76+2.97=67.41usd

    10%commercial sodium hypochlorite cost :

    10% commercial sodium hypochlorite to the factory price is 200usd/T, and covert into active chlorine is 200usd/T, and the daily plant need available chlorine is 72 kg
    The daily cost   0.072x 2000= 144usd

     on site sodium hypochlorite daily cost saving:144-67.41=77usd
    investment cost analysis

    on site sodium hypochlorite generator equipment cost

    Equipment investment:66666.70usd(Including dosing system)

    commercial sodium hypochlorite generator

    investment: 10000.00usd

    cost:  onsite sodium hypochlorite generator cost more than commercial sodium hypochlorite

    66666.70-10000.00=56666.70usd
     final cost accounting every year
     operation fee:
     onsite sodium hypochlorite generator saving:77*365=28105.00usd
     invest fee:

    onsite sodium hypochlorite generator invest more than commercial sodium hypochlorite generator:66666.70-10000.00=56666.70usd

    on site sodium hypochlorite generator in cost saving(every yaer) :56666.70-28150.00=28516.70usd


    Equivalent to the sodium hypochlorite generator and goods nearly years to recover all investments The costs and benefits of sewage water disinfection by sodium hypochlorite depend on-site specific factors such as power costs, availability of brine water, safety ,and ease of use. Disinfection using hypochlorite is often the least expensive and most appropriate option.


    work shop :

    NaClO Solution Sodium Hypochlorite Generator Advantage Analysis 3 kg / h
