Large Split Type Industrial Electrolysis Of Brine 0.8 % NaCIO System 30 kg / h

Large Split Type Industrial Electrolysis Of Brine 0.8 % NaCIO System 30 kg / h

    • Large Split Type Industrial Electrolysis Of Brine 0.8 %  NaCIO System 30 kg / h
    • Large Split Type Industrial Electrolysis Of Brine 0.8 %  NaCIO System 30 kg / h
    • Large Split Type Industrial Electrolysis Of Brine 0.8 %  NaCIO System 30 kg / h
  • Large Split Type Industrial Electrolysis Of Brine 0.8 %  NaCIO System 30 kg / h

    Product Details:

    Place of Origin: CHINA
    Brand Name: CNJS
    Certification: ISO9001
    Model Number: CNJS-L30000

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: NEGOTIATION
    Packaging Details: wooden case
    Delivery Time: 20-45 work days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 20 sets per month
    Contact Now
    Detailed Product Description
    Highlight:

    Sodium Hypochlorite Plant

    ,

    Sodium Hypochlorite Production Process



    Large Split Type Industrial Electrolysis Of Brine 0.8 %  NaCIO System 30 kg / h





    Principle:

    CNJS-L series sodium hypochlorite generator is a newly and work through electrolysis of salt water , the whole system consists of electrolysis electrode assembly , rectification power and automatic control system , dissolving system , filtering system , ratio device and so on . The salt water is electrolyzed into sodium hypochlorite . Sodium hypochlorite is a kind of disinfection which can gets strong antivirus and bleach power.  Its working principle is:

      the sodium chloride solution under the certain voltage effect of the cell, a series of electrochemical reaction within the cell and the resulting solution is the NaClO solution. The main process can be simplified as follows:

                                                                                Electrode reaction:

    anode:2Cl--2e→Cl2

    cathode:2H++2e→H2

    Solution:2NaOH+Cl2→NaCl+NaClO+H2O


    Technical parameters:



    Type

    Power(V/Hz)

    concentration of liquid(mg/l)

    available chlorine (Kg/h)

    Flow (m3/h)

    Salt consumption (kg/d)

    Water consumption (m3/d)

    Power consumption   (kw)

    Size(m)      (l×w×h)

    CNJS-L30000

    380V/50Hz

    7-9

    30

    3.75

    2520

    60

    95

    1760*860*

    1950







    Work flow chart :

    Large Split Type Industrial Electrolysis Of Brine 0.8 %  NaCIO System 30 kg / h



    Automatic sodium hypochlorite generator system fully automatic production, contains the system



    A,Automatic dissolving salt tank :Including salt tank , liquid level control , dissolving salt pump , electric valves , piping and other components which could automatic transmission salt , dissolving salt , saturated brine

    B,Saturated brine filter :Including stainless steel two precision filter ,primary filtering accuracy 50um, secondary filtration precision 5um, use PP filter , the filter can be easily replaced, ensure clean brine ;

    C,Dilute brine tank :The saturated brine and production water has been diluted with 2.5 % weak brine water , for the power solutions

    D,Sodium hypochlorite generator host machine :Including electrolytic cell , electrolysis power , intelligent control center PLC , the control element, man-machine interface , PC communication module, the operator panel, the host stand, electric valves, electrical power distribution system

    E,Sodium hypochlorite solution storage tank :including hydrogen storage tank , exhaust equipment

    F,Automatic dosing and on-line monitoring system: including the inverter , corrosion metering dosing pump , online residual chlorine monitor , and the closed-loop control of chlorine

    G,Online instrument series : Production water pressure monitoring , dilute brine online salinity monitoring , temperature controller , flammable gas monitoring sensor , these monitoring instruments are all included alarm signal output



    Advantage of on-site sodium hypochlorite generator

    Large Split Type Industrial Electrolysis Of Brine 0.8 %  NaCIO System 30 kg / h          Large Split Type Industrial Electrolysis Of Brine 0.8 %  NaCIO System 30 kg / h

    CNJS Technology  Material: electrode after burn.                                                                Other :  Electrode thickness is only 1.0 mm,

    Full titanium 2mm base, iridium,                                                                                            common ruthenium iridium thickness thin, easy to   ruthenium oxide nano-coating,                                                                                                scaling easy to short circuit, the above is scaling
    the sub-25 coating thickness of 20 microns
    coating adhesion, long service life.




                                                                          Large Split Type Industrial Electrolysis Of Brine 0.8 %  NaCIO System 30 kg / h
