Customised Sodium Hypochlorite For Drinking Water Electrolysing Plant

Customised Sodium Hypochlorite For Drinking Water Electrolysing Plant

    • Customised Sodium Hypochlorite For Drinking Water Electrolysing Plant
    • Customised Sodium Hypochlorite For Drinking Water Electrolysing Plant
    • Customised Sodium Hypochlorite For Drinking Water Electrolysing Plant
  • Customised Sodium Hypochlorite For Drinking Water Electrolysing Plant

    Product Details:

    Place of Origin: CHINA
    Brand Name: CNJS
    Certification: ISO9001
    Model Number: CNJS-L3000

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: NEGOTIATION
    Packaging Details: wooden case
    Delivery Time: 20-45 work days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 20 sets per month
    Contact Now
    Detailed Product Description
    Available Chlorine: 7.0-9.0g/L Power Input: 380V, 50Hz
    Inlet Water Temperature: 5-27℃ Inlet Water Pressure: 0.2-0.4Mpa
    Electrolytic Liquid: 2.5~3% Weak Brine Content Available CL: ≥8000ppm
    Rated Current: Determined According To The Selected Product Model
    Highlight:

    Sodium Hypochlorite Plant

    ,

    Sodium Hypochlorite In Water Treatment



    Customised Sodium Hypochlorite For Drinking Water Electrolysing Plant





    Principle:



       The revolutionary CNJS-L series sodium hypochlorite generator is a newly and for on-site product of NaClO equipment and use for all kinds of needed NaClO disinfected. Its working principle is :the sodium chloride solution under the certain voltage effect of the cell, a series of electrochemical reaction within the cell and the resulting solution is the NaClO solution. The main process can be simplified as follows:



                                                                                Electrode reaction:

    anode:2Cl--2e→Cl2

    cathode:2H++2e→H2

    Solution:2NaOH+Cl2→NaCl+NaClO+H2O


    Technical parameters:



    Type

    Power(V/Hz)

    concentration of liquid(mg/l)

    available chlorine (Kg/h)

    Flow (m3/h)

    Salt consumption (kg/d)

    Water consumption (m3/d)

    Power consumption   (kw)

    Size(m)      (l×w×h)

    CNJS-L3000

    380V/50Hz

    7-9

    3

    0.375

    252

    9

    17.5

    900*700*1780





     Available chlorine: 7.0-9.0g/L ;           Power input: 380V, 50Hz  ;

     Inlet water temperature : 5-27℃ ;      Inlet water pressure: 0.2-0.4Mpa ;

     Salt consumption: 3.5kg/kg Cl2 ;       Water consumption: 125L/kg Cl2 ;



    Work flow chart :

    Customised Sodium Hypochlorite For Drinking Water Electrolysing Plant

    4,Automatic sodium hypochlorite generator system fully automatic production, contains the system

    A,Automatic dissolving salt tank :Including salt tank , liquid level control , dissolving salt pump , electric valves , piping and other components which could automatic transmission salt , dissolving salt , saturated brine

    B,Saturated brine filter :Including stainless steel two precision filter ,primary filtering accuracy 50um, secondary filtration precision 5um, use PP filter , the filter can be easily replaced, ensure clean brine ;

    C,Dilute brine tank :The saturated brine and production water has been diluted with 2.5 % weak brine water , for the power solutions

    D,Sodium hypochlorite generator host machine :Including electrolytic cell , electrolysis power , intelligent control center PLC , the control element, man-machine interface , PC communication module, the operator panel, the host stand, electric valves, electrical power distribution system

    E,Sodium hypochlorite solution storage tank :including hydrogen storage tank , exhaust equipment

    F,Automatic dosing and on-line monitoring system: including the inverter , corrosion metering dosing pump , online residual chlorine monitor , and the closed-loop control of chlorine

    G,Online instrument series : Production water pressure monitoring , dilute brine online salinity monitoring , temperature controller , flammable gas monitoring sensor , these monitoring instruments are all included alarm signal output

    Advantage of on-site sodium hypochlorite generator



    Compared with other brand



    CNJS Technology

    other brand

    Advantages of CNJS

    Appearance

    CNJY Y1000 on-site sodium hypochlorite generation split type multifunctional

    CNJY Y1000 on-site sodium hypochlorite generation split type multifunctional

    Other equipment framework will rust after three months and  three years later, will affect the service life of equipment. CNJY equipment framework use alumina material, and does not rust



    Space

    Host machine size:1200*860*1950

    Host machine :2000*1000*2200              Control cabinet:850*700*1800          rectifier:500*1000*1100                 Host machine , Control cabinet , rectifier can not put in one rom together , need anther device room

    saving space Easy to install and operate

    Raw material

    refined salt or Industrial salt

    refined salt

    A wide scope of utility, economy and low operating cost

    Inlet water requirements

    Depend on actual situation need a water softener or not

     indispensable a water softener

    Can reduce unnecessary link,  increase equipment safety.

    Brine concentration

    Salt brine mixing device, fully dissolved, ensure the stability of brine concentration.

    No mixing device, brine concentration is not stable.

    The stable liquid concentration,extend equipment service life.

    Dilute brine ratio

     water injector ratio

     normal valve

    High accuracy, more safety

    Generator fixed way

    All moulds are fixed, equipment installation is more stable

    With simple metal ring, need to reinforce the equipment

    CNJY Y1000 on-site sodium hypochlorite generation split type multifunctional

    Structure of electrode slices

    Bipolar type, in series, big gap, large flux

    Bipolar type,small gap, small flux

    Big flux , easy to control temperature equipment,electrode service long life

    Thickness of electrodes

    2mm

    1.5mm

    Long life of electrode, resistance to deformation, not short-circuited.

    Electrode coating technology

    nano- coated up to 20 ruthenium iridium oxide particles , coating thickness of 2- microns , 25 times of coating can ensure positive side high produ ing and long life

    Normal ruthenium iridium thickness thin, easy to deformation.

    Coating adhesion, long service life

    Electrode gap

    Big gap and flux

    Small gap and flux

    Low temperature big flux  equipment, high efficiency.

    Details :

                                                       Customised Sodium Hypochlorite For Drinking Water Electrolysing Plant.


    For CNJS technology: titanium plate one-piece flange with electrodes, and the high sealing ability, strong resistance to pressure.




                                                   Customised Sodium Hypochlorite For Drinking Water Electrolysing Plant








    Other manufacturers: long tubular, flange piece only a rubber ring between the electrode and compressive ability is poor, easy to leakage.





    workshop :

    Customised Sodium Hypochlorite For Drinking Water Electrolysing Plant



    Customised Sodium Hypochlorite For Drinking Water Electrolysing Plant
