chlorination disinfectant in swimming pool water treatment with low power cosumption

chlorination disinfectant in swimming pool water treatment with low power cosumption

    • chlorination  disinfectant in swimming pool water treatment with low power cosumption
    • chlorination  disinfectant in swimming pool water treatment with low power cosumption
  • chlorination  disinfectant in swimming pool water treatment with low power cosumption

    Product Details:

    Place of Origin: CHINA
    Brand Name: CNJS
    Certification: ISO9001
    Model Number: CNJS-R-400

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: NEGOTIATION
    Packaging Details: wooden case
    Delivery Time: 7-15 work days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 100 SETS /month
    Contact Now
    Detailed Product Description
    Available Chlorine: 0.8% Input Power: Customized
    Inlet Water Pressure: 0.2-0.4Mpa Environmental Temperature: 0-40 Degrees
    Content Available CL: 7000~9000ppm Salt Consumption: 3.5kg/kg Cl2

    chlorination disinfectant in swimming pool water treatment with low power cosumption




    Technical parameters :



    TYPE

    Available chlorine (g/h)

    flow

    (L/h)

    Salt

    consumption

    (kg/H)

    Rated power

    (kw)

    Size

    (mm)

     (L×W×H)

    CNJS-R400

    400

    80

    1.2

    2.3

    1700*900*1700





    Product feature:

    Chlorine concentration brine  :2.5%

    Power consumption : less than 3.5KW/ kg

    Content available CL :7000~9000ppm

    Working way : Unattended , fully automatic operation

    Life expectancy of anode coating : more than 5 years, and anode coating can be coated and used repeatedly

    Life expectancy of the electrode plates:more than 20 years

    Life expectancy of whole machine : more than 15 years



    Product system



    This product can be divided into three parts: water inflow and distribution, generating and storing, power control



    1.water inflow and distribution

    Including: softener, softened tank, flow regulating valve, dissolving tank, inlet water pump, as well as other piping and valves.



    2.Generating and storing

    Including: electrolysis tube, storing tank of sodium hypochlorite



    3.Power control

    Including: power controller cabinet



    why choose on CNJS Technology

    Safety

    Totally enclosed alumina framework , reduce the effect of environment on the equipment.

            All size of the equipment are equipped with strong fan , to ensure the safety during the operation of  the system.

            Industrial salt or refined salt all can suit for the equipment , so that in the absence of refined salt  regional can be security work.

    Energy-saving

    Using high frequency power switch , silicon ballast power saving 20% electricity than any other manufacturer.

    All equipment intelligent makes each part  more accurate.

    Environmental protection

    All equipment material is wading level standard, real national wading documents.

    All equipment product will not cause secondary pollution to environment.

    Efficient

    Good disinfection effect

    Truly unattended equipment, the efficiency is greatly increased.



    Application:

    • Small or medium sized waterworks chlorine dosing system reconstruction
    • Industry recycling water sterilization and algae killing
    • Oil field injection water sterilization
    • Restaurant, laundry and poultry disinfection
    • Disinfection of hotel, laundry and chicken farm
    • Small and medium hospital sewage treatment
    • Midway booster pump station chlorine supplement
    • Deep well water disinfection
    • Swimming pool water treatment
    • Landscape water treatment
    • Rain water collecting and reusing disinfection
    • Second time tank chlorine supplement
    • Fire water sterilization
    • Reclaimed water disinfection
