    Product Details:

    Place of Origin: CHINA
    Brand Name: CNJS
    Certification: ISO9001
    Model Number: CNJS-M-3000

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: NEGOTIATION
    Packaging Details: wooden case
    Delivery Time: 20-45 work days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 20 SETS PER MONTH
    Contact Now
    Detailed Product Description
    Available Chlorine: 0.8 % Power Input: 380V, 50Hz
    Inlet Water Temperature: 5-27℃ Inlet Water Pressure: 0.2-0.4Mpa
    Salt Consumption: 3.5kg/kg Cl2 Water Consumption: 125L/kg Cl2
    Electrolytic Liquid: 2.5~3% Weak Brine
    High Light:

    Onsite Sodium Hypochlorite Generation

    ,

    Sodium Hypochlorite Solution For Disinfection



    NaCIO Sodium Hypochlorite Uses In Wastewater Treatment 380V 50Hz





    Product introduction:



    Generation principle :CNJS - M series NaClO generator is a new type of NaClO solution for field production equipment , suitable for all kinds of needs NaClO disinfected venues . Its working principle is: the sodium chloride solution under the certain cell voltage function, in a series of electrochemical reaction occurs in the cell , the resulting NaClO solution , including the generation of NaClO through chemical equation can be expressed as follows :



                                                            NaCl+H2O+DC→NaClO+H2







    The electrode reaction:



    anode:2Cl--2e→Cl2



    cathode:2H++2e→H2



    solution:2NaOH+Cl2→NaCl+NaClO+H2O










    Technical parameters:



    Type : CNJS-M 3000



    Power(V/Hz) :380V/50Hz



    available chlorine (Kg/h) :3



    concentration of liquid(mg/l) :7-9



    Flow ( m3/h) :0.375


    Salt consumption ( kg /h ) :252


    Water consumption (m3/d) :9


    Power consumption   (kw):17.5



    Size(m)      (l×w×h) : 900*700*11780





    Work flow chart:



    NaCIO Sodium Hypochlorite Uses In Wastewater Treatment 380V 50Hz

    Product system:







    Generator part :



     Including generator , exchange heat ( options ) , Siemens touch screen and control system , etc.





    Storage Tank Part :



     Including NaClO tank, blower fan , Level gauge , Hydrogen gas detector, etc .



    Delivery Part :



     dosing Pump , flow meter , residual chlorine detector, etc







     Advantages on CNJS:



    Generator fixed way : All moulds are fixed, equipment installation is more stable



    Structure of electrode slices : Bipolar type, in series, big gap, large flux



    Thickness of electrodes : 2mm



    Electrode coating technology : Nano - coated up to 20 ruthenium iridium oxide particles , coating thickness of 2- microns , 25 times of coating can ensure positive side high producing and long life



    Electrode gap : Big gap and flux



    Dosing accuracy : Multilayer additive form, adding the high precision



    Intelligent control : Truly intelligent, fully integrated modular structure



    Power system : Using marine-grade high-frequency voltage constant current power supply, low heat, stable and integrated and equipment



    The man-machine interface : Small devices with Siemens touch screen, large equipment with industrial man-machine interface



    The PLC program : All size equipment configuration of the PLC, unattended and intelligent control.



    Security : Fully enclosed structure, high stability and high safety of the equipment



    Life expectancy of the electrode : More than 8 years



    Details :



    NaCIO Sodium Hypochlorite Uses In Wastewater Treatment 380V 50Hz  vs   NaCIO Sodium Hypochlorite Uses In Wastewater Treatment 380V 50Hz



                  For CNJS- technology                Other manufacturers:



     For CNJS- technology: titanium plate one-piece flange with electrodes, and the high sealing  ability, strong resistance to pressure.





    long tubular, flange piece  only a rubber ring between the electrode and  compressive ability is poor, easy to leakage.







    work shop :



    NaCIO Sodium Hypochlorite Uses In Wastewater Treatment 380V 50Hz
