Salt Water Electrolysis Sodium Hypochlorite Generation System with Ruthenium Iridium Coating

Salt Water Electrolysis Sodium Hypochlorite Generation System with Ruthenium Iridium Coating

    • Salt Water Electrolysis Sodium Hypochlorite Generation System with Ruthenium Iridium Coating
    • Salt Water Electrolysis Sodium Hypochlorite Generation System with Ruthenium Iridium Coating
    • Salt Water Electrolysis Sodium Hypochlorite Generation System with Ruthenium Iridium Coating
  • Salt Water Electrolysis Sodium Hypochlorite Generation System with Ruthenium Iridium Coating

    Product Details:

    Place of Origin: CHINA
    Brand Name: CNJS
    Certification: ISO9001
    Model Number: CNJS-L20000

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: NEGOTIATION
    Packaging Details: wooden case
    Delivery Time: 20-45 work days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 20 sets per month
    Contact Now
    Detailed Product Description
    High Light:

    Sodium Hypochlorite Plant

    ,

    Sodium Hypochlorite Production Process



    Salt Water Electrolysis Sodium Hypochlorite Generation System with Ruthenium Iridium Coating





    Principle:

     CNJS-L series sodium hypochlorite generator is a newly and work through electrolysis of salt water , the whole system consists of electrolysis electrode assembly , rectification power and automatic control system , dissolving system , filtering system , ratio device and so on . The salt water is electrolyzed into sodium hypochlorite . Sodium hypochlorite is a kind of disinfection which can gets strong antivirus and bleach power.  Its working principle is:

      the sodium chloride solution under the certain voltage effect of the cell, a series of electrochemical reaction within the cell and the resulting solution is the NaClO solution. The main process can be simplified as follows:

                                                                                Electrode reaction:

    anode:2Cl--2e→Cl2

    cathode:2H++2e→H2

    Solution:2NaOH+Cl2→NaCl+NaClO+H2O


    Technical parameters:

    Type

    Power(V/Hz)

    concentration of liquid(mg/l)

    available chlorine (Kg/h)

    Flow (m3/h)

    Salt consumption (kg/d)

    Water consumption (m3/d)

    Power consumption   (kw)

    Size(m)      (l×w×h)

    CNJS-L20000

    380V/50Hz

    7-9

    20

    2.5

    1680

    60

    65

    1760*860*

    1950







    Work flow chart :

    Salt Water Electrolysis Sodium Hypochlorite Generation System with Ruthenium Iridium Coating



    Automatic sodium hypochlorite generator system fully automatic production, contains the system



    A,Automatic dissolving salt tank :Including salt tank , liquid level control , dissolving salt pump , electric valves , piping and other components which could automatic transmission salt , dissolving salt , saturated brine

    B,Saturated brine filter :Including stainless steel two precision filter ,primary filtering accuracy 50um, secondary filtration precision 5um, use PP filter , the filter can be easily replaced, ensure clean brine ;

    C,Dilute brine tank :The saturated brine and production water has been diluted with 2.5 % weak brine water , for the power solutions

    D,Sodium hypochlorite generator host machine :Including electrolytic cell , electrolysis power , intelligent control center PLC , the control element, man-machine interface , PC communication module, the operator panel, the host stand, electric valves, electrical power distribution system

    E,Sodium hypochlorite solution storage tank :including hydrogen storage tank , exhaust equipment

    F,Automatic dosing and on-line monitoring system: including the inverter , corrosion metering dosing pump , online residual chlorine monitor , and the closed-loop control of chlorine

    G,Online instrument series : Production water pressure monitoring , dilute brine online salinity monitoring , temperature controller , flammable gas monitoring sensor , these monitoring instruments are all included alarm signal output



    Advantage of on-site sodium hypochlorite generator

    Salt Water Electrolysis Sodium Hypochlorite Generation System with Ruthenium Iridium Coating                                             Salt Water Electrolysis Sodium Hypochlorite Generation System with Ruthenium Iridium Coating



      CNJS Technology  Material:                                                                                                          Other :  Electrode thickness is only 1.0 mm,
       Full titanium 2mm base, iridium,                                                                                             common ruthenium iridium thickness thin, easy to      ruthenium oxide nano-coating,                                                                                                 scaling easy to short circuit, the above is scaling      the sub-25 coating thickness of 20 microns                                                                             electrode    after burn.                                               coating adhesion, long service life.









                                                                       Salt Water Electrolysis Sodium Hypochlorite Generation System with Ruthenium Iridium Coating
