Place of Origin: | CHINA |
Brand Name: | JSSHG |
Certification: | ISO9001 |
Model Number: | CNJS |
Minimum Order Quantity: | 1set |
---|---|
Price: | dollar |
Packaging Details: | Wooden case |
Delivery Time: | 4 weeks |
Payment Terms: | T/T |
Supply Ability: | 10 set per month |
Automatic: | Sodium Hypochlorite Generation | Long Life: | TA1 Electrode Piece |
---|---|---|---|
Efficient: | Intelligent Unattended |
Why choose Jiashang Technology
Design strength, production quality, safety assurance, project performance
1,Technical strength
2,Safety protection of system design
a. Safety of raw material storage
b. Main components are equipped with spare parts to ensure safe operation
c. Indoor hydrogen concentration detection
d. Inflow flow detection e. Water inlet pressure detection
f. Liquid level detection of electrolytic tube g. Electrode temperature detection
h. Electrolytic current detection i. Electrolytic voltage detection
j. Brine concentration detection k. Strong exhaust dilutes hydrogen
l. Wind pressure detection m. More accurate dosing and safer effluent
n. Dosing flow monitoring
p. The reserve of sodium hypochlorite can be increased according to the actual situation
3,Electrode structure of patented technology
Electrode plate: plate electrode. The anode and cathode base materials of the electrode are all made of pure titanium TA1 material. In the electrolysis process, the cathode is protected, while the anode is lost, so the anode surface must be protected by coating. The anode surface of jsshg brand generator electrode is coated with ruthenium and iridium oxide with particle fineness of 20 nm, which is treated by nanotechnology. The coating is divided into more than 18 times, and the coating thickness is 20 microns, which can ensure the long-term Stable service life.
4,Fully transparent electrolytic cell
The following figure:
Our electrolyzer is the only fully transparent design in China, including flanges. When dilute brine is electrolyzed, the electrolytic state is clear at a glance. For electrolysis, the most important thing to pay attention to is whether the electrolytic cell is scaling and whether the electrode works in a safe state. The fully transparent electrolytic cell can visually see the actual situation, so as to better protect the electrolytic cell. The electrolyzer is equipped with liquid level protection, low temperature protection, high temperature protection, low current protection, ultra-high current protection, low voltage protection and ultra-high voltage protection. Once there is an abnormality, the system will send an alarm signal and stop working.
